FPZ增強聚丙烯自吸泵 塑料自吸泵
新款32FPZ-11增強聚丙烯塑料泵介紹：
FPZ耐腐蝕自吸離心泵，采用增強聚丙烯（RPP）一次注塑成型。機械強度高，耐腐蝕性能強，結構上有D.J一格的科學性，泵腔內設有吸液室，儲液室、回液止回閥、氣液分離室、回流孔。只需在DY次開機前灌注引液，以后不必重復灌注引液，吸入管不需安裝液下底閥，工作時機械密封不需另加冷卻水冷卻，操作簡便、安全無泄漏，是取代液下泵的Z佳產品，適用于-14℃~+80℃（RPP）的各種腐蝕性介質的輸送。
新款40FPZ-18 65FPZ-28 80FPZ-32塑料自吸泵介紹：
FPZ工程塑料自吸泵一次注塑成型、機械強度高，耐腐蝕性能強，結構上有D.J一格的科學性。泵腔內設有吸液室、儲液室、回液止回閥、氣液分離室、回流孔，只需在DY次開機前灌注引液，以后不必重復灌注引液，在吸送介質時，液體可時斷時續，斷液15分鐘內來液可繼續吸送，機械密封不需另加冷卻水冷卻，操作簡便，安全，無泄漏，是取代液下泵的Z佳產品。
泵材質，采用無毒、無污染，增強聚丙烯RPP（適用溫度-14℃~100℃）一次性注塑成型。
| 增強聚丙烯耐腐蝕泵 | ||||||||
| 型號規格 | 口徑 | 流量 | 揚程 | 吸程 | 轉速 | 電壓 | 電機 | |
| 進口 | 出口 | m³/h | M | M | r/min | v | 功率kw | |
| FP20-15-100(105) | 20 | 15 | 3 | 7 | 4 | 380 | 0.75 | |
| FP32-25-100(104) | 32 | 25 | 4 | 7 | 6.5 | 220 | 0.55 | |
| FP32-25-105(103) | 32 | 25 | 6.3 | 8 | 6.5 | 380 | 0.75 | |
| FP40-32-125(102) | 40 | 32 | 12.5 | 20 | 6.5 | 380 | 1.5 | |
| FP50-40-130(101.5) | 50 | 40 | 13 | 22 | 6.5 | 380 | 2.2 | |
| FP65-50-150(101) | 65 | 50 | 25 | 25 | 6 | 380 | 4 | |
| 50FP-22 | 50 | 40 | 13 | 22 | 6 | 2900 | 380 | 2.2 |
| 65FP-25 | 65 | 50 | 20 | 25 | 6 | 380 | 4 | |
| 80FP-28 | 80 | 65 | 50 | 28 | 4 | 380 | 5.5 | |
| 80FP-32 | 80 | 65 | 50 | 32 | 4 | 380 | 7.5 | |
| 25FPZ-10(D)(自吸) | 25 | 20 | 2.5 | 10 | 3 | 220 | 0.55 | |
| 32FPZ-11(D)(自吸) | 32 | 25 | 3.4 | 11 | 3 | 380 | 0.75 | |
| 32FPZ-18(D)(自吸) | 40 | 32 | 11 | 18 | 4 | 380 | 1.5 | |
| 32FPZ-20(D)(自吸) | 50 | 40 | 13 | 20 | 4 | 380 | 2.2 | |
| 65FPZ-28(自吸) | 65 | 50 | 20 | 28 | 4 | 380 | 4 | |
| 80FPZ-28（自吸） | 80 | 65 | 50 | 28 | 4 | 380 | 5.5 | |
| 80FPZ-32(自吸) | 80 | 65 | 50 | 32 | 4 | 380 | 7.5 | |
FPZ增強聚丙烯自吸泵 塑料自吸泵尺寸圖：
以下為老款介紹（供老用戶維護或更換配件參考用）
老款泵浦概述：
FPZ自吸泵，采用增強聚丙烯（CFR-PP）一次注塑成型，機械強度高，耐腐蝕性能強，自吸泵結構上有D.J一格的科學性，泵腔內設有吸液室、儲液室、回液止回閥、氣液分離室、回流孔。只需在DY次開機前灌引液，以后不必重復灌注引液，在吸送介質時，液體可時斷時續，斷液15分鐘內來液可繼續吸送，機械密封不需另加冷卻水冷卻，操作簡便、安全無泄漏，是取代液下泵的Z佳產品。
CFR-PP材質：無毒、無污染、耐一般酸堿鹽類，工作溫度-14℃～80℃。
FPZ 型增強聚丙X自吸泵(老款)性能參數表
|
型號
|
流量
m3/ |
揚程
(m) |
自吸高度
（m） |
自吸時間
s/m |
功率
KW |
進出口徑
mm |
與電機軸聯接形式
|
|
25FPZ-10
|
2.5
|
10
|
3
|
60
|
0.75
|
1 1/2
|
直聯式
|
|
32FPZ-11
|
3.5
|
11
|
3
|
60
|
0.75
|
1 1/2
|
直聯式
|
|
40FPZ-18
|
11
|
18
|
4
|
60
|
1.5
|
40/30
|
直聯式
|
|
50FPZ-20
|
13
|
20
|
4
|
60
|
2.2
|
50/40
|
直聯式
|
|
25FPZ-10
|
2.5
|
10
|
3
|
60
|
0.75
|
1 1/2
|
聯軸式
|
|
32FPZ-11
|
3.5
|
11
|
3
|
60
|
0.75
|
1 1/2
|
聯軸式
|
|
40FPZ-18
|
11
|
18
|
4
|
60
|
1.5
|
40/30
|
聯軸式
|
|
50FPZ-20
|
13
|
20
|
4
|
60
|
2.2
|
50/40
|
聯軸式
|
|
65FPZ-28
|
20
|
28
|
4
|
60
|
4
|
65/50
|
聯軸式
|
|
80FPZ-30
|
50
|
30
|
4
|
60
|
7.5
|
80/65
|
聯軸式
|
產品概述：
103型耐腐蝕塑料離心泵,適用于輸送酸、堿、鹽等腐蝕性液體,在長期的使用實踐中,深受各界用戶歡迎。
隨著我國工業的發展和三廢治理的普遍重視,對泵的結構和性能又提出了新的要求,這就是:重量輕、體積小、耐腐蝕性能好。
為此,本單位設計并試制了一種以J330聚丙烯為原料的新式103型塑料離心泵,在同系列的泵產品中充分顯示了其結構XJ、重量輕、體積小、使用壽命長等優點。
The product summary :
The 103 mould corrosion preventives plastics centrifugal pumps are suitable in carrying the corrosiveness liquid such as acid , alkali and salt etc , and receive all circles users to welcome deeply in the long-term use practice .
What the development of the industry along with our country and the three wastes were administered universally attaches importance to , and structure and capability to the pump have been put forward the new requirement again , and this is : Weight is light and the volume is small and the corrosion preventive capability is good . this unit design and having manufactured experimently one kind of new type 103 moulds plastics centrifugal pump that takes J330 s polypropylene as the raw material have fully shown the merits such as his structure is advanced and weight is light and the volume is small and service life is long etc in with the pump product of series therefor 。
用途:
①主要用于輸送不含懸浮顆粒的酸堿鹽體腐蝕液體。 ②泵體材料無毒性。
The use :
1. Chiefly used to carry not the sour alkali salt aspect of Han s suspension anything small and roundish corruption liquid . 2. Pump aspect nonpoisonous nature of material .
產品結構 ：
103型離心泵為臥式結構，由微型交流電動機驅動；泵體材料選用J330聚丙烯塑料制成，葉輪呈單片狀，并采用氮化硅和樹脂石黑機械密封，軸的連接為螺紋套式連接。
103型塑料離心泵具有結構緊湊，密封性能良好，終久耐磨、耐腐蝕性能優良、裝拆方便等優點。
The product structure :
The 103 moulds centrifugal pumps are the horizontal structure , and by the minisize alternating current motive drive The pump aspect material chooses J330 s polypropylene plastics to be made , and the impeller assumes one-chip form , and using Shi Hei of silicon nitride with resin machinery to seal up , linking of axle for the whorl set type connection .
It is compact that the 103 moulds plastics centrifugal pumps possess the structure , and it is good to seal up the capability , merits such as the eventually wear-resisting , corrosion preventive capability is fine and loads to dismantle convenient etc .
本塑料塑料離心泵,廣泛用于輸送酸、堿、鹽等腐蝕性液體,在長期的使用實踐中,深受各界用戶歡迎。
102A型塑料離心泵,有無毒硬質聚氯乙烯塑料與ABS工程塑料兩種,供廣大用戶選擇采用。本泵主軸全部采用不銹鋼材料,密封采用優質機械密封,102A型具有體積小、重量輕、結構簡單、使用方便、效率高等特點。
These plastics centrifugal pumps are extensively used to carry the corrosiveness liquid such as acid , alkali and salt etc , and receive all circles users to welcome deeply in the long-term use practice 102A s mould plastics centrifugal pumps have or not hard nature polyvinyl chloride plastics and two kinds in engineering plastics ABSs of poison , and supply that vast user selects and uses .
This pump principal axis completely uses the stainless steel material , and seals up using high quality machinery to seal up , and 102A s mould possesses that the volume is small and weight is light and the structure is simple and the use is convenient and the efficiency advanced characteristic.
用途(The use)：
主要用于輸送酸堿等腐蝕性液體，但不得用于輸送若干對ABS工程塑料有顯著作用的化學品，如芳烴、脂肪烴的鹵素衍生物，酮類及濃酸堿等。
Chiefly being used to carry the corrosiveness liquid such as acid alkali etc , but must not be used to carry several pairs of ABS s engineering plastics to have chemistry article of notable effect , like the halogen derivative of aromatic hydricarbon and fat hydrocarbon , ketone and dense acid alkali etc
產品結構(The product structure):
102A型塑料離心泵為臥式結構，由Y系列小型鼠籠型電動機驅動，泵體材料選用ABS工程塑料制成。泵體內腔光滑，葉輪為閉式，采用機械密封和耐酸橡膠圈密封等二種，全軸為不銹鋼用套筒式連接。
102A s mould plastics centrifugal pumps are for the horizontal structure , and by the small-size squirrel cage mould electromotor drive of Y s series , the pump aspect material chooses ABS s engineering plastics to be made inside the pump aspect cavity is smooth , and the impeller is for the closing type , and use that closes and the acidproof rubber of machinery is 2 kinds ring close etc , and Quan Zhouwei s stainless steel links with the sleeve type.
本單位生產耐腐蝕塑料離心泵數十年來,產品一直是自來水、化工等行業所需要的配套設備,本企業堅持質量DY,不斷提高產品性能,深受廣大用戶歡迎。
105型自吸式塑料離心泵是本單位Z新產品,其特點是體積小、外形美觀、結構合理、質量可靠、使用方便。
The product summary
This unit production corrosion preventive plastics centrifugal pumps was continuously the necessary equipments that the trade needs such as running water and chemical industry etc several ten years , and the quality first is persisted in by this industry , and constantly raises the product capability , and receives vast user to welcome deeply .
105 moulds are the newest product of this unit from inhaling type plastics centrifugal pumps , and his characteristic is that the small and outer mould of volume is pleasing to the eye and the structure is reasonable and the quality is reliable and the use is convenient .
附表：塑料泵材質的耐腐蝕性能：
介質 濃度 CFR-PP 介質 濃度 ABS 25℃ 65℃ 90℃ 20℃ 60℃ 80℃ 硫酸H2SO4 98% √ √ ○ 硫酸H2SO4 ＜30% √ × 70% √ √ √ 30-70% ○ × 1-50% √ √ √ ＞75% × × 硝酸HNO3 濃 √ √ ○ 硝酸HNO3 10% √ ○ 20% √ √ √ 20% √ 10% √ √ √ 25-35% ○ √ ＞50% × × 鹽酸HCL 0-30% √ ○ × 鹽酸HCL ＜30% √ × 氫氟酸 √ ○ × 氫氟酸 ＜10% √ × 40-48% √ × 醋酸 1-50% √ √ √ 醋酸 ＜20% √ ○ 磷酸 各種濃度 √ √ √ ＞30% × × 氫氧化鈉 √ √ √ 氫氧化鈉 √ √ √ 氯化鈉 √ √ √ 氯化鈉 √ √ × 氯化鐵 √ √ 乙醇 √ √ √ 乙醇 √ √ 漂白液 √ √ √ 漂白液 ○ ○ ×
說明：√——良好； ○——可用、但有腐蝕； ×——不可用、腐蝕嚴重
以下為新款參數：
| FP(Z)增強聚丙烯耐腐泵詳細參數 | |||||
| 型號 | 電機功率(KW) | 進口(mm) | 出口(mm) | 流量 | 揚程 |
| 32FP(Z)-11D | 0.75 | 32 | 25 | 3.6 | 11 |
| 40FP(Z)-18D | 1.5 | 40 | 32 | 10 | 18 |
| 50FP(Z)-22D | 2.2 | 50 | 40 | 15 | 22 |
| 50FP(Z)-25D | 3 | 50 | 40 | 15 | 25 |
| 65FP(Z)-28D | 4 | 65 | 50 | 18 | 28 |
| 65FP(Z)-32D | 5.5 | 65 | 50 | 28 | 32 |
| 80FP(Z)-30D | 7.5 | 80 | 65 | 50 | 30 |
| 100FP-40D | 11~15 | 100 | 80 | 100 | 40 |
